| Max. Fabric Width | ≤800mm |
| Max.Effective Printing Width | ≤730mm |
| Effective Printing Length | 300-1200mm |
| Printing Speed | 50-130m/min (Based on bag size and ink floating) |
| Model | YX-G800 |
| Suitable material | PP Woven Fabric (Tube) and other tube materials 50-150g/m2 (kraft-paper plastic three-in-one fabric, non-woven fabrics) |
| Max. Fabric Width | ≤800mm |
| Max.Effective Printing Width | ≤730mm |
| Effective Printing Length | 300-1200mm |
| Printing Speed | 50-130m/min (Based on bag size and ink floating) |
| Printing Roller | ceramic anilox rollers |
| Motion controllers | Inovance |
| Servo Motor | Inovance |
| Inverter | Inovance |
| Colour Mark | Panasonic |
Remark
* The data depends on weaving construction, size and weight of fabric, specification and quality of tape.
** Specification and dimensions are subject to change without prior notice.
*** Special specification and versions on request.
Yongxu's high-speed lamination and printing machines provide great flexibility and significant cost savings in our manufacturing process.
The high-speed 6 shuttle circular looms not only meet diverse bag type demands but also substantially improve our production efficiency.
The high-speed circular looms save 20% power with low maintenance costs, providing us with high-quality, high-efficiency production solutions.
Yongxu's equipment allows us to deliver durable, cost-effective packaging solutions that truly meet our customers' branding and durability needs.
The new winder integrates perfectly with our old line, saving us costs while significantly improving overall production efficiency.
One worker can operate the entire automatic cutting-sewing machine, achieving a high capacity of 30-50 pcs/min with excellent ease of operation.
