| Vacuum Screw | 38CrMoAIA, with Nitriding treatment |
| T-Die | 45#, Hard chrome plated, mirror polishing |
| Tape Width | 2.0-4.0mm |
| Tape Usage Application | For Standard Woven Bag, Rope and Tarpaulin |
| Model | YX-115/M800 |
| Raw Material Mixing Ratio | 100%virgin PP, or 100% recycling PP, or virgin PP mixed with recycling PP. |
| Vacuum Screw | 38CrMoAIA, with Nitriding treatment |
| T-Die | 45#, Hard chrome plated, mirror polishing |
| Tape Width | 2.0-4.0mm |
| Tape Usage Application | For Standard Woven Bag, Rope and Tarpaulin |
| Filter Net | Easy To Change |
| Godets | Steel roller hard chromium-plated |
| Winding speed | 100-160m/min |
| Standard items | Optional items |
| 01) Automatic loader | 01) Equipment for processing HDPE |
| 02) Extruder | 02) Vented-screw extruder |
| 03) Standard Filer | 03) Automatic screen changing filter |
| 04) Standard T-die | 04) Second T-die |
| 05) Water quenching tank | 05) T-die for special tape |
| 06) Flat film haul-off unit with 4 godets | 06) Film haul-off unit |
| 07) Water scraper device | 07) Edge trim recycling system |
| 08) Tape slitting device | 08) Tape fibrillator |
| 09) Stretching heating arc plate (length 3.2m) | 09) Electrostatic eliminator |
| 10) Standard stretching unit with 5 godets | 10) Additional stretching godets |
| 11) Annealing heating arc plate (length 2.0m) | 11) Additional traction godets |
| 12) Standard traction unit with 3 godets | 12) Winding unit for special bobbin |
| 13) Tape collection unit with 1 roller | 13) Magnetic winder |
| 14) Cam winder | 14) Water chiller |
| 15) Electrical and control system | 15) Cooling water tower |
Remark
* The data depends on weaving construction, size and weight of fabric, specification and quality of tape.
** Specification and dimensions are subject to change without prior notice.
*** Special specification and versions on request.
